R900953434 H-4WMM22J70/ H-4WMM22J7X/ Injap Arah Dengan Penggerak Tuas Tangan
901155517 F/43R978915499 H -4WMM22C7X/F/VR901225251 H-4WMM22C7X/FJR901220541 H-4WMM22C7X/JR900955339 H-4WMM22D7X/R9108{8MM22D7X/R908} 772344 H{{42 }}WMM22D7X/F/VR900955600 H-4WMM22E7X/R900957897 H-4WMM22E7X//VR901000219 H-4WMM22E7X//VT12E7X//VT12R0590 966275 H{{63} }WMM22E7X/F/43VR900713421 H-4WMM22E7X/F/VR901040737 H-4WMM22F7X/R901027622 H-4WMM22F7X/F/VR901040737 H-4WMM22F7X/R901027622 H-4WMM22F7X/FR902}95 337 H-4 WMM22G7X//43R900956480 H-4WMM22G7X/FR900957926 H-4WMM22G7X/F/43R978917190 H-4WMM22G7X/F/F/F/VR9010} 247210 H-4 WMM22H7X/R901444580 H-4WMM22H7X//VR900967207 H-4WMM22H7X/FR900769914 H-4WMM22H7X/FJR920746 00953434 H{{126 }}WMM22J7X/R900959482 H-4WMM22J7X//VR900953980 H-4WMM22J7X/FR900948930 H-4WMM22J7X/F1/VR9029 262839 H-4 WMM22L7X/R900957326 H-4WMM22L7X/FR901075027 H-4WMM22M7X/R900709430 H-4WMM22M7X//43VR9012}H9012340 7542 H-4WMM22P7X/ F901039298 7}}WMM22S11-7X /R901113719 H-4WMM22S1-7X/R900752334 H-4WMM22T7X/R900967006 H-4WMM22T7X/FR90096X{7202}} 1 4098 WMM22W
H-4WMM 4/3 dan 4/2 injap arah, dengan penggerak tuil tangan
Saiz 16 … 32
Siri komponen 7X, 5X
Tekanan operasi maksimum 350 bar
Aliran maksimum 1100 l/min
Ciri-ciri
Injap kili arah dikendalikan terus dengan penggerak tuil tangan
Corak porting mengikut DIN 24340 borang A dan ISO 4401
dengan pulangan musim bunga atau penahan, pilihan
Mekanisme aktuasi dilindungi daripada pencemaran dan kemasukan kelembapan
Hujung kepala dengan mekanisme penggerak boleh ditukar tanpa membuka injap
Suis kedudukan induktif dan penderia jarak (tanpa sentuhan)
Jenis Kod:
|
01 |
|
02 |
03 |
04 |
05 |
06 |
|
07 |
08 |
09 |
10 |
|
H |
– |
4 |
WMM |
|
|
|
/ |
|
|
|
* |
|
01 |
Tekanan operasi maksimum 350 bar |
H |
|
02 |
4 port utama |
4 |
|
Penggerakan |
||
|
|
||
|
03 |
Tuas tangan |
WMM |
|
04 |
Saiz 16 |
16 |
|
Saiz 25 |
22 |
|
|
Saiz 32 |
32 |
|
|
05 |
Simbol kili, cth C, E dsb., lihat Simbol |
|
|
06 |
NG16 dan 25 – Siri komponen 70 hingga 79 (70 hingga 79: dimensi pemasangan dan sambungan tidak berubah) |
7X |
|
NG32 – Siri komponen 30 hingga 39 (30 hingga 39: dimensi pemasangan dan sambungan tidak berubah) |
5X |
|
|
07 |
Denganmusim bunga kembali |
tiada kod |
|
Dengan deten |
F |
|
|
Pemantauan kedudukan kili(NG16 dan 25 sahaja) |
||
|
|
||
|
08 |
Tanpa suis kedudukan |
tiada kod |
|
Kedudukan kili dipantau "a" |
QMAG24 |
|
|
Kedudukan kili dipantau "b" |
QMBG24 |
|
|
Kedudukan rehat yang dipantau |
QM0G24 |
|
|
Bahan meterai |
||
|
|
||
|
09 |
meterai NBR |
tiada kod |
|
Meterai FKM (meterai lain atas permintaan) Perhatikan keserasian pengedap dengan cecair hidraulik yang digunakan. |
V |
|
|
10 |
Butiran lanjut dalam teks biasa |
*
|
Rexroth Type H-4WMM22 Serie directional valve with hand tuil actuation on Sale, Short lead time, Best price!!!
| R901155517 | H-4WMM22C7X/ |
| R978915086 | H-4WMM22C7X/ |
| R901355967 | H-4WMM22C7X//V |
| R900722769 | H-4WMM22C7X/F |
| R900777428 | H-4WMM22C7X/F/43 |
| R978915499 | H-4WMM22C7X/F/V |
| R901225251 | H-4WMM22C7X/FJ |
| R901220541 | H-4WMM22C7X/J |
| R900955339 | H-4WMM22D7X/ |
| R900738114 | H-4WMM22D7X/F |
| R900772344 | H-4WMM22D7X/F/V |
| R900955600 | H-4WMM22E7X/ |
| R900957897 | H-4WMM22E7X//V |
| R901000219 | H-4WMM22E7X//VT12 |
| R900952059 | H-4WMM22E7X/F |
| R900966275 | H-4WMM22E7X/F/43V |
| R900713421 | H-4WMM22E7X/F/V |
| R901040737 | H-4WMM22F7X/ |
| R901027622 | H-4WMM22F7X/F |
| R900952782 | H-4WMM22G7X/ |
| R900730337 | H-4WMM22G7X//43 |
| R900956480 | H-4WMM22G7X/F |
| R900957926 | H-4WMM22G7X/F/43 |
| R978917190 | H-4WMM22G7X/F/V |
| R901043375 | H-4WMM22G7X/J |
| R900247210 | H-4WMM22H7X/ |
| R901444580 | H-4WMM22H7X//V |
| R900967207 | H-4WMM22H7X/F |
| R900769914 | H-4WMM22H7X/FJ |
| R900746882 | H-4WMM22J11-7X/ |
| R900953434 | H-4WMM22J7X/ |
| R900959482 | H-4WMM22J7X//V |
| R900953980 | H-4WMM22J7X/F |
| R900948930 | H-4WMM22J7X/F/V |
| R900956935 | H-4WMM22J7X/J |
| R901262839 | H-4WMM22L7X/ |
| R900957326 | H-4WMM22L7X/F |
| R901075027 | H-4WMM22M7X/ |
| R900709430 | H-4WMM22M7X//43V |
| R901234160 | H-4WMM22M7X/F/V |
| R901037542 | H-4WMM22P7X/F |
| R901039298 | H-4WMM22Q7X/ |
| R900976605 | H-4WMM22R7X/ |
| R901225263 | H-4WMM22R7X/FJ |
| R901220536 | H-4WMM22R7X/J |
| R900710672 | H-4WMM22S11-7X/ |
| R901113719 | H-4WMM22S1-7X/ |
| R900752334 | H-4WMM22T7X/ |
| R900967006 | H-4WMM22T7X/F |
| R900967728 | H-4WMM22W48-7X/ |
| R901164098 | H-4WMM22W48-7X//V |
| R901206568 | H-4WMM22W48-7X/J |
| R900956909 | H-4WMM22W7X/F |
| R900956384 | H-4WMM22Y7X//43 |
